Dometic Fridge Fan Kit Fitting Instructions

Reduce the gap if necessary with deflector plates or foam insulation.

Dometic fridge fan kit fitting instructions.

Optimal installation of dometic 3 way absorption refrigerators in caravans motor homes and campers. Primary consideration is that the gap between the back of fridge and caravan wall should not exceed 25mm. The dometic ar vkit fridge ventilation kit ensures optimal ventilation for your absorption refrigerator. An opening toward the outside at floor level in the refrigerator compartment must be provided for ventilation of heavier than air fuel gases.

Make sure the polarity is correct. The gap above the rear of the fridge body and the underside of the worktop should closed. The ventilation kits must be installed and used without modification. If fitting a fan unit it pays to install as per dometic s instructions.

Refrigerator model listed in the table. Before starting up the device for the first time check whether the operating voltage and the battery voltage match see type plate. Connect your refrigerator to a plug socket which is fuse protected with at least 15 a at 12 v or 7 5 a at 24 v fig. Switch to manual m and check the fans are running.

Dometic absorption refrigerators for caravans and motor homes and campers are built to provide excellent cooling performance even in high ambient temperatures. The lower vent of the recommended kits is provided. Feeding the cable plug from the fan unit inside the van. Attach the power feed ve and ve via a fuse.

Secure the control unit. Difficulties with the performance of the refrigerator can be avoided by. Thermostat controlled and extremely easy to install the fridge ventilation kit is particularly recommended for use in high ambient temperatures or intense sunlight.
